FCW.63XX

FCW.6308 connection or class C profile bent square washer is used to install any connection or fastener on the open wall of the profile, especially for U-shaped support with rod hanger. The curved edge of this piece makes it fit better with the profile and prevents it from moving. | FCW.63XX

Categories , Tags , , , , , , , ,
Price :

Free

Download Model :
  • Revit 2021
download

Description

FCW.6308 connection or class C profile bent square washer is used to install any connection or fastener on the open wall of the profile, especially for U-shaped support with rod hanger. The curved edge of this piece makes it fit better with the profile and prevents it from moving. This connection is used for M8 size screw or hanger rod. FCW.6310 connection is also produced for M10 rod screw or pendant. | FCW.63XX
